Name: 2-10 Year Flood Level (North of 401, Foxboro)

Display Field: Year

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><P><SPAN>The delineated floodlines in this dataset were derived from the original Moira River Conservation Authority Flood Damage Reduction Program (FDRP) mapping from the 1980s. CAD files from these drawings were obtained by Quinte Conservation and the 2 and 10 year floodlines were superimposed in the drawings under the direction of Quinte Conservation Engineering staff. The orginal data and CAD files were drawn using NAD27. In order to transfer the data to a GIS environment the geographic coordinate system was defined as NAD27 for the .DWG file and then transformed to NAD83 UTM ZONE 18N using the North American Datum Conversion Utility (NADCON) transformation algorithm. This was accomplished using the utilities in ArcGIS.</SPAN></P></DIV></DIV>

Copyright Text: The CAD file that was used to import the data into a GIS environment can be found on the Quinte Conservation file server (\\vmfile\Company\Technical\Floodplain Mapping\Moira River CAD Floodline Drawings\401toFoxboro2yearOBSERVED_revised.dwg). The base data in this file, along with the 100 year floodline in this drawing, comes from the original 1980s FDRP mapping for the Moira River Conservation Authority.

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 305392.97670000046
YMin: 4896148.1447
XMax: 309637.26460000034
YMax: 4902221.2049
Spatial Reference: 26918  (26918)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: Year
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 10 Year
  Label: 10 Year
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [168, 0, 132, 255]
  Width: 2
• Value: 2 Year
  Label: 2 Year
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 0, 197, 255]
  Width: 2
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• SHAPE_Leng ( type: esriFieldTypeDouble, alias: SHAPE_Leng )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )
• OBJECTID_1 ( type: esriFieldTypeOID, alias: OBJECTID_1 )
• OBJECTID ( type: esriFieldTypeInteger, alias: OBJECTID )
• Year ( type: esriFieldTypeString, alias: 2 or 10 Year Storm Line, length: 20 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
