Name: Lots and Concessions

Display Field: GEOGRAPHIC_TOWNSHIP_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Location of Lots and Concessions based on the 19th-century era of initial settlement in Ontario, these lots were conceded (hence “concession”) by the Crown to individual applicants seeking title in exchange for raising a house, performing roadwork and ​land clearance, and ​money."A concession is a polygon feature that identifies a major subdivision of geographic townships. A concession is composed of contiguous lots. Ó Land Information Ontario. *A geographic township is a polygon feature that indicates the fundamental land subdivision fabric of the Province"Concession Area=1000-acre“Concession line” is principally an Ontario term for the straight country roads, parallel to one another, upon which farm lots face. In this version of the Ontario land survey, the 1000-acre block is 5/6 of a mile wide and 1 7/8 miles long.Source: https://geohub.lio.gov.on.ca/ Fields: 'OBJECTID', 'OGF_ID', 'CLASS_SUBTYPE', 'CLASS_SUBTYPE_NUM', 'LOT_IDENT', 'CONCESSION_IDENT', 'GEOGRAPHIC_TOWNSHIP_NAME', 'ROAD_ALLOWANCE_STATUS_FLG', 'RELATED_FEATURE_DESCR', 'LOCATION_ACCURACY', 'LOCATION_DESCR', 'VERIFICATION_STATUS_FLG', 'VERIFICATION_STATUS_DATE', 'SYSTEM_CALCULATED_AREA', 'USER_CALCULATED_METRIC', 'GENERAL_COMMENTS', 'GEOMETRY_UPDATE_DATETIME', 'EFFECTIVE_DATETIME', 'SHAPE', 'SHAPE.STArea()', 'SHAPE.STLength()'

Copyright Text: Belleville GIS, MNR, https://geohub.lio.gov.on.ca/

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 281691.92112790496
YMin: 4884886.314742541
XMax: 337947.2738669781
YMax: 4932597.96074072
Spatial Reference: 26918  (26918)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [252, 216, 189, 0]
Outline:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [130, 130, 130, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 30000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• OGF_ID ( type: esriFieldTypeDouble, alias: Ogf Id )
• CLASS_SUBTYPE ( type: esriFieldTypeString, alias: Class Subtype, length: 75 )
• CLASS_SUBTYPE_NUM ( type: esriFieldTypeInteger, alias: Class Subtype Num )
• LOT_IDENT ( type: esriFieldTypeString, alias: Lot Ident, length: 100 )
• CONCESSION_IDENT ( type: esriFieldTypeString, alias: Concession Ident, length: 100 )
• GEOGRAPHIC_TOWNSHIP_NAME ( type: esriFieldTypeString, alias: Geographic Township Name, length: 100 )
• ROAD_ALLOWANCE_STATUS_FLG ( type: esriFieldTypeString, alias: Road Allowance Status Flg, length: 8 )
• RELATED_FEATURE_DESCR ( type: esriFieldTypeString, alias: Related Feature Descr, length: 200 )
• LOCATION_ACCURACY ( type: esriFieldTypeString, alias: Location Accuracy, length: 25 )
• LOCATION_DESCR ( type: esriFieldTypeString, alias: Location Descr, length: 2000 )
• VERIFICATION_STATUS_FLG ( type: esriFieldTypeString, alias: Verification Status Flg, length: 10 )
• VERIFICATION_STATUS_DATE ( type: esriFieldTypeDate, alias: Verification Status Date, length: 8 )
• SYSTEM_CALCULATED_AREA ( type: esriFieldTypeDouble, alias: System Calculated Area )
• USER_CALCULATED_METRIC ( type: esriFieldTypeDouble, alias: User Calculated Metric )
• GENERAL_COMMENTS ( type: esriFieldTypeString, alias: General Comments, length: 2000 )
• GEOMETRY_UPDATE_DATETIME ( type: esriFieldTypeDate, alias: Geometry Update Datetime, length: 8 )
• EFFECTIVE_DATETIME ( type: esriFieldTypeDate, alias: Effective Datetime, length: 8 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.STArea() ( type: esriFieldTypeDouble, alias: SHAPE.STArea() )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
