Name: Intake Protection Zone 2

Display Field: Id

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: The Municipality will protect all municipal drinking water supplies and designated vulnerable areas which are so designated because of their importance as a drinking water source. The Quinte Region Source Protection Plan identifies the following types of vulnerable drinking water areas:• Surface Water Intake Protection Zones (IPZs);IPZ 2: a secondary protection zone of land and water, outside the IPZ 1, that surrounds a municipal water intake pipe. The IPZ 2 shows the area where pollutants and contaminants could reach the intake pipe within several hours.

Copyright Text: Belleville GIS, Planning, EDS

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 306325.28610000014
YMin: 4889403.409499999
XMax: 308734.8256000001
YMax: 4892705.718699999
Spatial Reference: 26918  (26918)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSBackwardDiagonal
Color: [230, 152, 0, 255]
Outline:
Style: esriSLSSolid
Color: [230, 152, 0, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [230, 152, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 50000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Id ( type: esriFieldTypeInteger, alias: Id )
• area_acres ( type: esriFieldTypeDouble, alias: area_acres )
• FNODE_ ( type: esriFieldTypeInteger, alias: FNODE_ )
• TNODE_ ( type: esriFieldTypeInteger, alias: TNODE_ )
• LPOLY_ ( type: esriFieldTypeInteger, alias: LPOLY_ )
• RPOLY_ ( type: esriFieldTypeInteger, alias: RPOLY_ )
• LENGTH ( type: esriFieldTypeDouble, alias: LENGTH )
• GIS.Belleville_IPZ_2.area ( type: esriFieldTypeDouble, alias: GIS.Belleville_IPZ_2.area )
• Shape_Leng ( type: esriFieldTypeDouble, alias: Shape_Leng )
• Source ( type: esriFieldTypeString, alias: Source, length: 20 )
• CA ( type: esriFieldTypeString, alias: CA, length: 10 )
• Status ( type: esriFieldTypeString, alias: Status, length: 10 )
• Vuln_score ( type: esriFieldTypeDouble, alias: Vuln_score )
• Municipali ( type: esriFieldTypeString, alias: Municipali, length: 25 )
• Zone ( type: esriFieldTypeString, alias: Zone, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
