Name: Well Head Protection Overlay

Display Field: OBJECTID_1

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: The WHPAs are classified based on the following factors:• WHPA A: the area within a 100 metre radius from a wellhead that is considered the most vulnerable area for ground water intakes.• WHPA B: the area in which a pollutant released in this area could reach the well within two years (excluding WHPA-A)• WHPA C: the area in which a pollutant released in this area could reach the well within five years (excluding WHPA-A and WHPA-B)The implementing Zoning By-law of this Plan will prohibit land uses in the Intake Protection Zones and Wellhead Protection Areas that may present a risk of contaminating this drinking water intake source.d) In the event of a conflict between this Plan and the significant threat policies of the approved Quinte Region Source Protection Plan, the Source Protection Plan prevails in accordance with the Clean Water Act (2006).Note that there are areas of overlap within the areas designated as IPZs and WHPAs in Point Anne.

Copyright Text: Planning , GIS

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 317185.9955000002
YMin: 4892259.3258
XMax: 317694.16559999995
YMax: 4892734.429099999
Spatial Reference: 26918  (26918)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: Feature
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Well Head Protection Area - A
  Label: Well Head Protection Area - A
  Description: N/A
  Symbol:
  Style: esriSFSBackwardDiagonal
  Color: [168, 112, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [168, 112, 0, 255]
  Width: 0
• Value: Well Head Protection Area - B
  Label: Well Head Protection Area - B
  Description: N/A
  Symbol:
  Style: esriSFSBackwardDiagonal
  Color: [230, 152, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [230, 152, 0, 255]
  Width: 0
• Value: Well Head Protection Area - C
  Label: Well Head Protection Area - C
  Description: N/A
  Symbol:
  Style: esriSFSBackwardDiagonal
  Color: [255, 211, 127, 255]
  Outline:
  Style: esriSLSSolid
  Color: [255, 211, 127, 255]
  Width: 0
Transparency: 75
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [130, 130, 130, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 5000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID_12 ( type: esriFieldTypeOID, alias: OBJECTID_12 )
• OBJECTID_1 ( type: esriFieldTypeInteger, alias: OBJECTID_1 )
• OBJECTID ( type: esriFieldTypeInteger, alias: OBJECTID )
• Id ( type: esriFieldTypeInteger, alias: Id )
• GIS.Belleville_WHPA.area ( type: esriFieldTypeDouble, alias: GIS.Belleville_WHPA.area )
• System ( type: esriFieldTypeString, alias: System, length: 15 )
• WHPA ( type: esriFieldTypeString, alias: WHPA, length: 5 )
• VSA ( type: esriFieldTypeDouble, alias: VSA )
• intrin_vul ( type: esriFieldTypeString, alias: intrin_vul, length: 5 )
• uncertaint ( type: esriFieldTypeString, alias: uncertaint, length: 5 )
• Shape_Leng ( type: esriFieldTypeDouble, alias: Shape_Leng )
• Shape_Le_1 ( type: esriFieldTypeDouble, alias: Shape_Le_1 )
• Feature ( type: esriFieldTypeString, alias: Feature, length: 500 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
